Intshayelelo
Ufakelo lwe-weld lweHydraulic luchane{0}}izinto eziyinjineli eziyilelwe ukudala uqhagamshelo olomeleleyo, olusisigxina kwiinkqubo eziphezulu zoxinzelelo lwe-hydraulic. Ezi zifakelo zidityaniswe ngokuthe ngqo kwimibhobho, iityhubhu, okanye i-hydraulic manifolds, iqinisekisa ukomelela okuphezulu kunye nokumelana nokuvuza kwimfuno yezicelo zamashishini.
Iinkcukacha
|
ISIQENDU INOMBOLO. |
UMCHANGA E |
I-HOSE BORE |
IMILINGANISELO |
||||
|
DN |
ISIKHWAMA |
A |
C |
S1 |
S2 |
||
|
22611D-04-04 |
G1/4"X19 |
6 |
04 |
23.5 |
5.5 |
19 |
19 |
|
22611D-06-06 |
G3/8"X19 |
10 |
06 |
26.5 |
6.3 |
22 |
22 |
|
22611D-08-08 |
G1/2"X14 |
12 |
08 |
31 |
7.5 |
27 |
27 |
|
22611D-10-08 |
G5/8"X14 |
12 |
08 |
32 |
9.5 |
30 |
30 |
|
22611D-12-08 |
G3/4"X14 |
12 |
08 |
33 |
10.9 |
32 |
32 |
|
22611D-12-12 |
G3/4"X14 |
20 |
12 |
34 |
10.9 |
32 |
32 |
|
22611D-16-16 |
G1"X11 |
25 |
16 |
35.5 |
11.7 |
41 |
41 |
|
22611D-20-20 |
G1.1/4"X11 |
32 |
20 |
43.5 |
11 |
50 |
50 |
Iiparamitha/iDatha yobuGcisa
|
Eyoqobo |
Zhejiang, China |
Umhla wokuzisa |
Kuyathethwana |
|
Isiqinisekiso |
GB/T19001-2016 idt ISO9001:2015 |
Ukupakisha |
umgangatho wokuthumela ngaphandle |
|
Izinto eziphathekayo |
Intsimbi yeCarbon |
Iwaranti |
1 unyaka |
|
Ixesha lokuhlawula |
TT |
MOQ |
2000 |
|
Imeko |
Entsha |
Umbala |
I-zinc emhlophe, i-zinc yombala |
Malunga neNkampani
Iingenelo
OEM Manufacturing Ukugqwesa
{0}Endlwini yemveliso enolawulo olupheleleyo kumgangatho kunye neendleko
I-Machining ye-CNC ephuculweyo kunye ne-welding ezenzekelayo yokuhambelana ngokuchanekileyo
Ukudityaniswa ngokuthe nkqo ukusuka ekufumaneni izinto ezikrwada ukuya kwimveliso egqityiweyo
IMigangatho yoMgangatho engayekeleliyo
Ukulandeleka kweMathiriyeli: Zonke imathiriyeli ekrwada ziza nezatifikethi zovavanyo lokusila
Uvavanyo olungqongqo: Yonke into ifakwa:
Uvavanyo loxinzelelo lwe-Hydrostatic (ukuya kuthi ga kwi-1.5x yoxinzelelo olulinganisiweyo)
Ukuqinisekiswa komda ngeCMM
Ukuhlolwa okubonakalayo kunye nomphezulu
Iziqinisekiso: ISO 9001, CE, PED, kunye nokuthotyelwa kwe-API kuyafumaneka
Ukusebenza kweMveliso ephezulu
Uyilo olulungiselelwe i-weld prep yokungena kunye nokomelela okugqibeleleyo
Ukuchaneka{0}}imigangatho yokutywina eyenziwe ngoomatshini (SAE, JIC, imigangatho yeDIN)
Ukhetho olukhethekileyo lwemathiriyeli:
-imveliso yentsimbi yekhabhoni ephezulu-yemisebenzi enzima
I-316L ingenabala kwindawo enomhlwa
Cryogenic -ibakala ialloyi ubushushu obugqithisileyo
UbuNjineli beSiko lobuNjineli
Izisombululo ezilungiselelwe usetyenziso olulodwa:
{0}ubungakanani obungebubo nobungqingqwa bodonga
Ubume bomsonto obukhethekileyo
Imilinganiselo yoxinzelelo eqhelekileyo
Iimfuno zokwaleka zobunini
Inkxaso epheleleyo yobugcisa kwiqela lethu lobunjineli
Iingenelo zokukhuphisana
30-50% yokonga iindleko vs
Amaxesha okukhokela ngokukhawuleza: iintsuku ze-15-20 kwii-odolo eziqhelekileyo
Ii-MOQ eziguquguqukayo: Ukusuka kwiprototype ukuya kwimveliso yobuninzi
Inethiwekhi yeGlobal Logistics: Ukuhanjiswa okuthembekileyo kwihlabathi liphela
Ubunakho bethu bokuVelisa
Izixhobo: Intsimbi yeCarbon, intsimbi engatyiwa, intsimbi yealloyi, intsimbi ephindwe kabini
Ubungakanani: 1/8" ukuya kwi-3" (DN6 ukuya kwi-DN80)
Amanqanaba oxinzelelo: Ukuya kuthi ga kwi-10,000 PSI (ibha engama-700)
Imigangatho: SAE, JIC, DIN, ISO, BSPP/BSPT, ORFS
FAQ
Umbuzo: Ziziphi izixhobo ze-weld ze-hydraulic?
A: Izixhobo ze-Hydraulic weld ziziqhagamshelo ezikhethekileyo ezisetyenziswa kwiinkqubo zamanzi ukudibanisa iityhubhu okanye imibhobho ngokukhuselekileyo ngokudibanisa i-welding. Baqinisekisa{1}ubungqina bokuvuza,{2}}noxinzelelo oluphezulu loqhagamshelo kwizicelo ezinje ngoomatshini boshishino, izixhobo zokwakha, kunye neenkqubo zamandla olwelo.
Umbuzo: Zeziphi izinto ezifakwa kwi-hydraulic weld?
A: Izinto eziqhelekileyo ziquka:
Intsimbi yeCarbon - Yeyokusetyenziswa ngokubanzi kwe-hydraulic.
Insimbi engenasici - Ukumelana nokugqwala kwiindawo ezinzima.
Umbuzo: Zeziphi iintlobo ze-hydraulic weld fittings ezikhoyo?
A: Iintlobo ezidumileyo ziquka:
I-Weld elbows (i-90 degree, i-45 degree) - Ukwenzela utshintsho lwendlela.
I-Weld tees - Ukuhamba kwe-branching.
Iimanyano ze-Weld - Uqhawulo olulula.
Iingono ze-Weld & adapters-Ukwenzela utshintsho phakathi kobukhulu obahlukeneyo okanye iintlobo zoqhagamshelwano.
Q: Loluphi uqikelelo loxinzelelo olunabo izifakelo ze-hydraulic weld?
A: Amanqaku oxinzelelo ayahluka ngokomathiriyeli, ubungakanani, kunye noyilo. Amanqaku aqhelekileyo aqala kwi-3,000 PSI ukuya kwi-10,000 PSI okanye ngaphezulu, kuxhomekeke kuhlobo olufanelekileyo kunye nokusetyenziswa.
Umbuzo: Ndikhetha njani i-hydraulic weld fitting efanelekileyo?
A: Qwalasela:
Uxinzelelo lwenkqubo kunye neemfuno zobushushu
Ukuhambelana nolwelo (ioyile yehydraulic, amanzi, iikhemikhali)
Ubungakanani betyhubhu/imibhobho kunye nemigangatho yentambo (SAE, JIC, DIN, njl.)
Ukufaneleka kwezinto (ukumelana nokubola, amandla)
Umbuzo: Ngaba i-hydraulic weld fittings ingaphinda isetyenziswe emva kwe-welding?
A: Hayi, izixhobo zeweld zidityaniswa ngokusisigxina kwityhubhu okanye imibhobho kwaye azinakuphinda zisetyenziswe xa sele zidityanisiwe. Kuqhagamshelo olususekayo, qwalasela imisonto ephothiweyo okanye eneflanged.
Umbuzo: Zeziphi iindlela ze-welding ezisetyenziselwa ukufakwa kwe-weld ye-hydraulic?
A: Iindlela eziqhelekileyo ziquka:
I-TIG (i-Tungsten Inert Gas) i-welding - Ngokuchanekileyo, i-welds ecocekileyo.
I-MIG (i-Metal Inert Gas) i-welding - Ukukhawuleza kwi-welding kwiindawo zoshishino.
I-Stick welding (SMAW) – Yeyomsebenzi{0}}obunzima.
Umbuzo: Ndiqinisekisa njani ukuba {{0}ubungqina beweld evuzayo?
A: Sebenzisa iindlela ezifanelekileyo ze-welding (indawo ecocekileyo, imimiselo yokushisa echanekileyo).
Qinisekisa ukulungelelaniswa okufanelekileyo phambi kwe-welding.
Landela imigangatho yoshishino (ISO, SAE, ANSI).
Ukuqhuba uvavanyo loxinzelelo emva kokufakwa.
Umbuzo: Ngaba izifakelo ze-hydraulic weld ziyahambelana nazo zonke ii-hydraulic fluids?
